Complete PDF version of the Service Manual for the Malaguti SpiderMax 500. A MUST for every SpiderMax owner.
Download: Immediately after payment!
OEM Original factory workshop manual.
Models covered by this manual: 2006 to 2016
Number of pages: 104 pages
Table of contents:
This PDF repair manual can be downloaded right after the payment process in complete, on the device of your choice.
We do not offer printed manuals, for the following reasons:
- it is more eco-friendly to use a digital version
- your manual never gets dirty or greasy
- you can always choose to print the specific page(s) you need to work on your bike
- you receive your manual immediately after payment
- it is searchable
Malaguti Spider Max GT500
Between 2006 and 2016, Malaguti developed the Spidermax RS500, a single-cylinder, four-stroke scooter. At 6000 RPM, the maximum torque was 29.5 ft/lbs (40.0 Nm). At 7250 RPM, the claimed horsepower was 39.56 HP (29.5 KW).
The engine was a four-stroke, liquid-cooled single cylinder. A displacement of 493.0 cubic centimeters is achieved via a bore of 94.0mm and a stroke of 71.0mm. A single overhead camshaft supplied fuel (sohc).
The motorcycle features an automated gearbox. The dry clutch was used to control power.
It comes with a front tire measuring 120/80-16 and a rear tire measuring 150/70-16. Stopping was accomplished using two floating discs. Front hydraulic two-piston calipers and rear single disc hydraulic two-piston calipers.
The front suspension consisted of a tele-hydraulic fork and 41 mm stanchions, while the rear suspension had a swinging engine and twin hydraulic shock absorbers with adjustable preloading springs. The Spidermax RS500 had a petrol tank that held 3.83 gallons (14.50 liters). The bike was just 449.74 pounds (204.0 Kg). The wheelbase measured 58.66 inches (1490 mm).
Malaguti SpiderMax GT500 is a Scooter bike produced by Malaguti. Regarding the chassis characteristics, which are responsible for road holding, handling behavior, and ride comfort, the Malaguti SpiderMax GT500 has a V-BOX aluminum monococque structure frame with 41 mm telescopic hydraulic fork in front suspension and two hydraulic shock absorbers with adjustable spring preloading in the rear suspension. Front tire sizes are 120/80-16, while rear tire sizes are 150/70-16.
