Yamaha V-Star 950 / V-Star 950 Tourer Service Manual (2009)

Yamaha introduced the V-Star 950 and V-Star 950 Tourer for the 2009 North American model year, with sales beginning in December 2008. Yamaha developed the pair around a “Sporty & Classic Cruiser” concept aimed at riders who wanted full-size cruiser proportions without the weight and bulk of the larger-displacement machines that dominated the segment. The standard model provided the basic cruiser package, while the Tourer added a windshield, leather-look sidebags and a passenger backrest as standard equipment. Yamaha's official 2009 V Star 950 launch release documents the original positioning and technical specification.

The new 942 cm³ engine was an air-cooled, four-stroke 60-degree V-twin with SOHC valve gear and electronic fuel injection. Its 85.0 × 83.0 mm bore and stroke and 9.0:1 compression ratio were tuned around strong low-speed and midrange response rather than high-rpm performance. Yamaha used rigid engine mounting to emphasize the V-twin pulse, while fuel injection and a three-way catalytic converter brought modern fuel metering and emissions control to the traditional air-cooled cruiser layout. Power is transmitted through a wet multi-disc clutch, five-speed constant-mesh transmission and low-maintenance belt final drive, making the platform a fuel-injected middleweight V-twin cruiser with straightforward mechanical architecture.

The chassis was also new for the model. A steel double-cradle frame, 1,685 mm wheelbase and low 675 mm seat height created the long-and-low proportions expected of a cruiser, while Yamaha emphasized lighter handling than the V Star 1300. The standard V-Star 950 weighs 278 kg ready to ride in the factory specification, while the Tourer is 298 kg with its touring equipment. Both use an 18-inch front and 16-inch rear cast wheel, a 41 mm conventional fork, rear link suspension, a 320 mm front disc and 298 mm rear disc. The 16.7-liter fuel tank and relaxed riding position support longer-distance use as well as everyday cruising.

Within Yamaha's model-code system the motorcycles in this manual belong to the XVS950 family. The factory specifications identify XVS95Y and California-spec XVS95YC for the standard model, plus XVS95CTY and XVS95CTYC for the Tourer. Yamaha later used related XVS950 naming in other markets and on later 950 cc cruiser derivatives, but this publication should be treated according to the model-year evidence inside it rather than the broader life of the platform. For related documentation, browse the Yamaha V-Star 950 manual category.

This listing is based on the 369-page factory service publication whose wiring diagrams are explicitly labeled for the XVS95Y/XVS95YC/XVS95CTY/XVS95CTYC 2009 models. It includes maintenance, engine, chassis, fuel-injection, electrical and troubleshooting procedures plus the factory wiring diagram. Although the PDF metadata contains a 2009-2012 title, no 2010-2012 supplement sections are present in the manual body, so the verified catalog coverage is 2009 only.
