Kawasaki Ninja ZX-6R Service Manual (2005)

The 2005 Kawasaki ZX6R represented a further development of Kawasaki's 636 cc supersport platform. The factory identifies this model as ZX636-C1, replacing the earlier ZX636-B1 designation used on the 2003 generation. Kawasaki retained the enlarged 636 cc displacement that distinguished the road-focused ZX-6R from the 599 cc class limit used in some racing categories, while continuing to develop the motorcycle around a compact, high-revving inline-four package.

The ZX636-C1 uses a 636 cc fuel-injected supersport engine with liquid cooling, DOHC cylinder heads and four cylinders. Factory specifications give a 68.0 × 43.8 mm bore and stroke and a 12.9:1 compression ratio. The DFI system uses four 38 mm Keihin TTK throttle bodies, primary and secondary fuel injectors, digital ECU control and an exhaust butterfly valve system. Drive passes through a wet multi-disc clutch, six-speed constant-mesh transmission and chain final drive.

The chassis reflects the model's track-oriented design. Kawasaki specifies a tubular diamond frame, 25-degree rake, 106 mm trail and a 1,390 mm wheelbase. Suspension consists of an upside-down telescopic fork with 120 mm travel and a Uni-Trak rear system with 135 mm travel. Seventeen-inch radial tires are paired with dual front discs and a single rear disc. The factory lists a 164 kg dry mass, 820 mm seat height and 17 L fuel capacity.

Kawasaki's official 2005 Ninja ZX-6R Owner Center page identifies the model as ZX636-C1 and lists the ZX636C/D service-manual family. The following 2006 model is separately identified by Kawasaki as ZX636C6F/ZX636D6F. For related factory documentation, browse the Kawasaki Ninja ZX6R service manual category. This listing is therefore limited to the 2005 ZX636-C1 explicitly covered by the uploaded PDF rather than extending the manual to the 2006 model without supporting documentation.
