Suzuki GSXR1000

Suzuki GSX-R 1000 K5-K6 Repair Manual (2005-06)

Complete PDF version of the Service Manual for the Suzuki GSX-R 1000 K5-K6. A MUST for every GSX-R owner.

Download: Immediately after payment!

OEM Original factory workshop manual.

Models covered by this manual: 2005 and 2006

Number of pages: 548 pages

Table of contents:

Suzuki GSXR1000 Service Manual 2005

This PDF repair manual can be downloaded right after the payment process in complete, on the device of your choice.

We do not offer printed manuals, for the following reasons:

  1. it is more eco-friendly to use a digital version
  2. your manual never gets dirty or greasy
  3. you can always choose to print the specific page(s) you need to work on your bike
  4. you receive your manual immediately after payment
  5. it is searchable

Paypal Secure checkout

Suzuki GSX-R 1000

The Suzuki GSX-R1000 is a sport bike in Suzuki‘s GSX-R motorcycle series. It was debuted in 2001 to replace the GSX-R1100 and is powered by a 988 cc (60.3 cu in) inline four-cylinder, four-stroke engine that is liquid-cooled.

2005 (K5, K6)

The engine and chassis of the 2005 GSX-R1000 were redesigned. It weighed 4.4 lb (2.0 kg) less than the previous model, yet the engine had a higher piston displacement of 11 cc (0.67 cu in). It had a completely redesigned frame that reduced the entire length of the bike by 1.6 in (41 mm) while only lowering the wheelbase by 0.02 in (0.51 mm). At the front, there were new brakes with radial mounted calipers and 310 mm (12.2 in) discs. The new titanium silencer (catalytic in Europe) was reported to be designed to minimize turbulence. This model weights just 365 pounds dry, placing it towards the top of the power-to-weight ratio rankings. This weight reduction came at the expense of durability difficulties, with frame breaking reported in 2005-2006 versions.

The tested wet weight of the 2005 model is 444 lb (201 kg). The power output is 147.3 horsepower (109.8 kW) and the max torque is 75.4 ftlbf (102.2 Nm), both at the rear wheel. In addition, in 2005, Suzuki replaced the brand’s complete name with a single “S” emblem on the tank of all models.

With the exception of a minor cosmetic tweaks, the 2005 model was carried over to 2006. The highest speed of the 2006 model was measured to be 178 mph (286 km/h).

Source: Wikipedia
