Triumph Daytona 675 R / Street Triple R Repair Manual (2013-17)

Triumph Daytona 675 R / Street Triple R Repair Manual (2013-17)

Complete PDF version of the Service Manual for the Triumph Daytona 675 R / Street Triple R. A MUST for every Street Triple owner.

Download: Immediately after payment!

OEM Original factory workshop manual.

Models covered by this manual: 2013 to 2017

Number of pages: 697 pages

Table of contents:

Triumph Daytona 675

This PDF repair manual can be downloaded right after the payment process in complete, on the device of your choice.

We do not offer printed manuals, for the following reasons:

  1. it is more eco-friendly to use a digital version
  2. your manual never gets dirty or greasy
  3. you can always choose to print the specific page(s) you need to work on your bike
  4. you receive your manual immediately after payment
  5. it is searchable

Paypal Secure checkout


Triumph Daytona 675 / Street Triple

The Triumph Daytona 675 is a three-cylinder sport bike that was introduced in 2006. It is the smallest of the Triumph triples. Triumph Motorcycles built it to replace their four-cylinder Daytona 650. The 675 proved to be incredibly light, agile, and powerful; with a maximum power output of 128 bhp, it was also quite speedy, and it outperformed the Japanese 600 cc rivals. Triumph discontinued manufacture of the base model Daytona 675 in 2016, citing declining demand for supersport motorcycles and increasingly stringent European emission rules. Triumph produced the higher-spec Triumph Daytona 675R variant until the 2018 model year. Triumph registered a new trademark for the Daytona, fueling speculation of a future version with the new 765 cc engine.

The Triumph Street Triple is a naked or streetfighter motorcycle produced by Triumph Motorcycles that was originally introduced at the end of 2007. The bike is based on the Speed Triple 1050, but it has a retuned inline three cylinder 675 cc engine from the 2006 Daytona 675 sport bike.
